• Model NO.：CZL-15
• Scale Structure：Special Aluminium
• Operating Environment：Non Explosion Proof Loadometer
• Lightning Protection：Without Lightning Protection
• Treatment：Anodized
• Color：Silver
• Transport Package：Carton
• Specification：CE
• Trademark：hlh
• Origin：China
• HS Code：9031809090
• Production Capacity：500PCS,Month

Basic Info.

Model NO. CZL-15 Scale Structure Special Aluminium Operating Environment Non Explosion Proof Loadometer Lightning Protection Without Lightning Protection Treatment Anodized Color Silver Transport Package Carton Specification CE Trademark hlh Origin China HS Code 9031809090 Production Capacity 500PCS/Month

Product Description

CZL-15 Specifications:

Specifications:

1. Rated Load (t): 15t

2. Excitation Voltage (VDC): 9-15VDC

3. Precision (%F.S): 5%FS(0-60km/h), 10%FS(60-120km/h)

4. Operating Temperature(deg C): -20 To +60 deg C

5. Safe Overload (%F.S): 150%FS

6. Cable: 15m

7. Size: Length: 1250mm, 1500mm, 1750mm, Width: 500mm, Height: 50mm

 (Outline size and other screw thread available)



Packaging

Carton Size: 167x67x15cm

 Company Information

    Guangdong South China Sea Electronic Measuring Technology Co Ltd is specializing in producing resistance strain gauge, load cells, micro load cells, pressure sensors, portable dynamic axle weighing scales and other electrical measurement products.

    The company has the formidable scientific research strength, improve the strict quality assurance system and excellent production equipment. The main products of strain gauge, load cell are certificated by RoHS, OIML(issued by EU.) CE etc. , the company subordinate products all technical supervision department issued by the national metrology license. In 2004 and 2005 respectively awarded by "Guangdong province private S&T enterprises " and " the Guangdong Hi-tech enterprise" title, in 2007 Dongguan intellectual property office granted "the patent pilot enterprise".

    Our load cells, strain gauges, pressure transducers and portable axle weigh scales have been exported to the world for a long time and achieved a certain market share. We have representative in US, Canada, Germany, British, Russia, India, Australia, etc. By this, we push our high quality products to the world!





FAQ

 About samples:
Yes, we have stock for samples.
About guarantee:
Three months for free replacement and one year for free repair.

About factory:
We are original manufacturer with 700 employees in Dongguan.
About certificates:
OIML, CE, ROHS, ISO9001, SGS
