Panel Weighing Io Controlling Indicator RS485 or RS232 (B094C)
Hefei Brans Measuring And Controlling Technology Co., Ltd.- Weighing:All Capacity
- Accuracy:0.0001g
- Display Type:OLED
- Display Digits:128X64
- Measure Method:Automatic
- Shell Material:Plastic
Base Info
- Model NO.:B094C
- Application:Electronic Platform Scale and Weighing Scale
- Certification:OIML, CE
- Customized:Customized
- Screen:LED DOT Matrix Graph Dispiay
- Material:Plastic Housing
- Power:86~264VAC, 12W
- Type & Speed:24-Bit 200Hz
- Applications:Weighing, Checking Weighing, Filling, Bagging, Bat
- Transport Package:Standard Carton Packing
- Specification:96*48*76mm
- Trademark:BRANS
- Origin:China
- HS Code:9026209090
- Production Capacity:30000PCS,Year
Description
Basic Info.
Model NO. B094C Application Electronic Platform Scale and Weighing Scale Certification OIML, CE Customized Customized Screen LED DOT Matrix Graph Dispiay Material Plastic Housing Power 86~264VAC, 12W Type & Speed 24-Bit 200Hz Applications Weighing, Checking Weighing, Filling, Bagging, Bat Transport Package Standard Carton Packing Specification 96*48*76mm Trademark BRANS Origin China HS Code 9026209090 Production Capacity 30000PCS/YearProduct Description
1. NAME: 100-240Vac 50-60Hz Abs Material Weighing Indicator China (B094C)2. Specification
- Use for turning the analog force signal to digital output,the standard analog output signal and simple control of the occasion
- Analog output signal could be 4~20mA,0~±10V
- Digital communication interface as RS485 or RS232
- Multiple fltering and debugging modes make it easier to obtain the target value
- Power supply and signal are isolated,strong anti-interference,more stable data acquisition and output
- LED display,showing real-time weight value, peak value,etc.
- Comparable output, peak capture, peak comparison output
- Non-weight calibration, TEDS automatic calibration
- High-speed sampling and fast display
- DC24Vpower supply,voltage±10%,more secure and stable
- 35mm standard industrial DIN rail
Display | LED |
Output linear | <0.01% |
Comprehensive accuracy | better than 0.01% |
A/D Conversion speed | >100-400/second |
Accept sensor | ± 30mV |
Input load | 1~8*350Ω sensor |
Output specification | 4 - 20mA, 0 ± 10V |
Temp.effect on output | <10 ppm/ºC |
Temp.effect on zero | <10 uv/ºC |
Excitation voltage | 5VDC |
Power supply | 24 ± 10%VDC |
Power waste | <8W |
Communication interface | Isolated RS232/485 |
Switch in | Switching: 2 switching input,3 switching output (OC) |
Operation temp range | -40 ~ 85°C |
Weight approx. | 0.5kg |
Material | Plastic Shell |
IP Class | IP64 |
3. Introduction
In Brans, we provide a range of weighing indicators and force meters to suit various applications. We have everything from a simple load cell indicator used in floor scales to fully featured devices for operating truck scales. Browse our force meter range to find the right weight indicator to suit your needs.
To bring the most out of your electronic weight sensor solution, we can provide embedded programs for your load cell display. These handle filling and dosing applications as well as truck scale operation.Choose from a variety of housings for your load indicator including aluminum and stainless steel options.
When you request a weighing indicator from our standard product line, we will ship it to you immediately. Or we could make any non-standard indicators with our special functions requirements.
Beyond Components: Complete Weighing Solutions by BRANSOpting for all Brans weight indicator, you get more than just a single high-class component.
BRANS offers you a complete weighing solution adaptable to your needs: From sensors through to software and service. As a global technology and market leader, we can give you the service you need, when and where you need it. Just get in touch!
4. APPLICATIONS:
Weighing, Hazardous-Area weighing, Checking Weighing, Filling, Bagging, Batching, Data communications, Filling, Dosing and dispensing, Formulation, Tank / Silo / Hopper / Vessel Weighing, In-Process Quality Control
Opting for all Brans weight indicator, you get more than just a single high-class component. BRANS offers you a complete weighing solution adaptable to your needs: From sensors through to software and service. As a global technology and market leader, we can give you the service you need, when and where you need it. Just get in touch!
