• Model NO.：SCS-120
• Automation：Non Automation
• The Weighing Method：Static Truck Scale
• Scale Structure：U-Type Steel
• Operating Environment：Explosion-proof Loadometer
• Lightning Protection：With Lightning Protection
• Safety Overload：125%F.S.
• Section：1 Section in 2 Pieces
• Capacity：10t~120t
• Iterm Name：60t 70t 80t 90t 100t 120t Electronic Truck Weigh B
• Transport Package：According to Your Request
• Specification：3*16m, 3,3.2,3.4m*7-18m for option
• Trademark：SiMei
• Origin：China
• HS Code：84238910
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. SCS-120 Automation Non Automation The Weighing Method Static Truck Scale Scale Structure U-Type Steel Operating Environment Explosion-proof Loadometer Lightning Protection With Lightning Protection Safety Overload 125%F.S. Section 1 Section in 2 Pieces Capacity 10t~120t Iterm Name 60t 70t 80t 90t 100t 120t Electronic Truck Weigh B Transport Package According to Your Request Specification 3*16m, 3/3.2/3.4m*7-18m for option Trademark SiMei Origin China HS Code 84238910 Production Capacity 5000PCS/Year

Product Description

80ton 3*18m steel measuring tape weighing machine Electronic Truck Scale Weighbridge/vehicle weight china factory truck weighing digital scales

Weighbridge is a large set of scales, usually mounted permanently on a concrete foundation, that is used to weigh entire rail or road vehicles and their contents. By weighing the vehicle both empty and when loaded, the load carried by the vehicle can be calculated.
  Parameters:

Item Name	80ton 3*18m electronic truck scales weighbridges
Structure	U-Type
Material	Q235 steel
Dimension	3*18m
Capacity	80ton,100ton
Thickness of top plate	10mm
Height of scale	300mm
Load Cell	10pcs
Section parts quantity	4 section in 8 piceces
Dimension piece	4500x1500x300mm
weight	8.8t



No	Size(M)	section	Deadweight Tonnage	Table thickness(mm)	Load Cell(pcs)	Indicator(pcs)	Junction box(pcs)	Self weight
1	1*1	1pcs	1~3t	4	4	1	1	55kg
2	1.2*1.2	1pcs	1~3t	4	4	1	1	75kg
3	1.2*1.5	1pcs	1~3t	4	4	1	1	93kg
4	1.5*1.5	1pcs	1~3t	4	4	1	1	105kg
5	1.5*2	1pcs	1~3t	4	4	1	1	140kg
6	2*3	1pcs	1~3t	4	4	1	1	310kg
7	2.2*5	1pcs	10~20t	6/8	4	1	1	1.3T
8	2.5*6	1section/2pcs	10~30t	8	4	1	1	1.6T
9	3*9	2section/4pcs	40~60t	10	6	1	1	4T
10	3*10	2section/4pcs	60~80t	10	6	1	1	4.4T
11	3*12	3section/6pcs	60~80t	10	8	1	1	6T
12	3*16	3section/6pcs	80~120t	10	8	1	1	7.5T
13	3*18	3section/6pcs	100~200t	10	10	1	1	8.8T
14	3.2*16	3section/6pcs	100~200t	10	8	1	1	8T
15	3.2*18	4section/8pcs	100~200t	12	10	1	1	9.4T



Qingdao SiMEI Weighing Apparatus Co.,Ltd specialized in weighing equipment for Scientific  research, development and production,according to ISO9001 quality system management. The company was founded in 2007, since its establishment, adhere to the truth-seeking innovation, excellence enterprise philosophy, after years of continuous accumulation and development, has become one of the domestic scale of professional weighing equipment manufacturers.

Our products include truck scales/weighbridge,Platform scales,animal scales, junction box,weights, load cell,indicator,software and so on.

We have established mature scales and distributing agents all over the country, and all the salesman and distributors have the ability of service and technical support. They are ready to provide the customer before and after sales service. Currently,our products have been exported to several countries, and well sold in European, American, Asian, and African countries. The products are fully appraised by the customers.

To provide our best quality and best service . We are always innovating and surpassing on the basis of demands from the customer,quality first, enquire of the market and the people oriented.

We promise:the weighbridge you purchase from SMILE will come with one year warranty!
During this period,any damage caused by quality problem will get free spare parts for repair!Even after warranty period, you can still contact us for spare part purchase for maintenance!


CUTTING:

BENDING:
WELDING:

BLASTING
PAINTING:


Production Process:


 Company Certification:FAQ
1.Are you manufacturer or trading company
We are professional manufacturer of weighbridge,truck scale and floor scales.
2.Warranty
   1 year.
During this period,any damage caused by quality problem will get free spare parts for repair.Even after warranty period, you can still contact us for spare part purchase for maintenance.
2.How to install scale?
The detail install manual is prepared together with scale,
Also technical engineer can be visiting supervise install if you required.
3.Who should i contact for service(repair,calibration)?
You can contact through sales to feedback to keda technical center department to get prompt service for repair and calibration.
4.Do you calibrate scale before shipment?
Yes,we already calibrate scale and test all parts before shipment,so it can use working directly after install.
5.Delivery Term
We accept EXW,FOB,CFR and CIF,etc.
6.Payment
1).T/T
2).L/C at sight
3).MIC Trade Assurance
4).Western Union
