• Model NO.：HLT
• Diameter of Meter Wheel：159.15
• Wire Diameter：30~150mm
• Speed：10m,Min
• Meter Counting Accuracy：0.1%
• Product Name：Belt Type Measuring Cable Meter Counter^
• Voltage：380V,50Hz
• Delivery Time：20 Days After Getting Deposit
• Transport Package：Standard Seaworthy Package
• HS Code：847940000
• Production Capacity：1000sets,Year

Basic Info.

Model NO. HLT Diameter of Meter Wheel 159.15 Wire Diameter 30~150mm Speed 10m/Min Meter Counting Accuracy 0.1% Product Name Belt Type Measuring Cable Meter Counter^ Voltage 380V,50Hz Delivery Time 20 Days After Getting Deposit Transport Package Standard Seaworthy Package HS Code 847940000 Production Capacity 1000sets/Year

Product Description

High Accurate Belt Type Meter Counter for Steel Rope&Cable Length Measuring^ Belt type high precision meter counter is a special equipment used to measure the length of cables and other media. The tracked meter counter is dragged together after the measuring medium is clamped by the upper and lower tracks. The length of the crawler is the length of the measured medium. The length of the crawler track is the length of the pitch line that the crawler wheel turns, that is, the product of the crawler wheel pitch and the number of teeth. The encoder installed on the active crawler shaft measures the number of turns the crawler has turned. After conversion, the length of the medium can be obtained and recorded. The upper crawler is lifted up and down by the hand wheel and the screw rod, and the lower crawler is lifted up and down by the air cylinder. The lifting distance is determined by the outer diameter of the medium being measured.






II.Main parameters
Two horizontal guide wheels are used, the meter wheel is plated with hard chrome, and the compression wheel is covered with polyurethane to increase the friction. The compression is controlled by the cylinder and controlled by the SMC pressure regulating valve. The meter is mechanically counted, with encoder output, which can be connected to customers PLC as an electronic meter signal

Diameter of meter wheel: 159.15
Wire diameter: Φ30~150
Speed:10m/min
The number of meters is displayed on the electronic meter counter
Meter counting accuracy: ±0.1%



Machine detail


Relevant machinery

- Cable extrusion machine
A.Description
The unit comfortable soft PVC, such as poly(PVC by hot press method to be extruded insulation wire core)
B.Technical parameter

Type & Size	Screw Dia. (mm)	L/D ratio	Screw speed (rpm)	Main motor (kw)	Barrel heating power (kw)	Temp. contr. zones (body/cross head)	Max. output capacity (PVC) (kg/h)
SJ30X25	20	25:1	5-150	11	3.6	3/2	20
SJ45X25	45	25:1	10-120	15	9	3/2	50
SJ65X25	65	25:1	10-100	30	16	4/4	120
SJ90X25	90	25:1	10-100	90	30	4/4	280
SJ120X25	120	25:1	7-68	132	54	6/4	580
SJ150X25	150	25:1	6-60	185	88	6/4	880
SJ200X25	200	25:1	4-40	250	140	7/4	1100

-Cable puller/caterpillar
Mainly used for various cable production lines for single machine or front and rear double traction.
Machine details



Clients Visiting




Factory show
