• Model NO.：TSC
• Scale Structure：Steel I Beam
• Operating Environment：Non Explosion Proof Loadometer
• Lightning Protection：With Lightning Protection
• Transport Package：Bulk
• Specification：3.4m en option
• Trademark：HIWEIGH
• Origin：China
• HS Code：8423899010
• Production Capacity：20000PCS,Year

Basic Info.

Model NO. TSC Scale Structure Steel I Beam Operating Environment Non Explosion Proof Loadometer Lightning Protection With Lightning Protection Transport Package Bulk Specification 3.4m en option Trademark HIWEIGH Origin China HS Code 8423899010 Production Capacity 20000PCS/Year

Product Description

I beams Module Structure
Stronger I beams structure, with steel bars. Modules design for easy loading in truck or container.

Concrete Platform*
Longer time for operation, not worry of rust any more.
With adjusting cabinet *concrete not included in the shipping list.

Easy Installation
Easy installation, labor work saving

PLATFORM
Structure designed with H beams. Modules design for container/truck load. Width of 3m or 3.4m option. Length from 16m to 24m* * other length customized demand * concrete not included in the shipping list.

LOAD CELL
OIML approved M36i column load cell. Stainless steel material.Hermetically sealed, IP68 . Optional HM9B model.

INDICATOR
S.S housing with IP65 protection. 240×128 dot matrix LCD. High accuracy up to 10,000e. Anti-vibration and anti-surge design. Easy to operation with big LCD display. Multi interface: RS232, RS485, Erthernet, etc.  Super anti-interference technology. Analog or digital working mode for choice.

Models

Part No.	410023	410024	410025	410026
Models	TSC316	TSC318	TSC321	TSC324
Capacity	80Ton	100Ton	100Ton	120Ton
Division	20kg	20kg	20kg	20kg
Platform size	3x16m	3x18m	3x21m	3x24m



Part No.	410027	410028	410029	410030
Models	TSC3416	TSC3418	TSC3421	TSC3424
Capacity	80Ton	100Ton	100Ton	120Ton
Division	20kg	20kg	20kg	20kg
Platform size	3.4x16m	3.4x18m	3.4x21m

Company Information
We have been devoted ourselves to the development and improvement of weighing technology and system for about 20 years, we also take the swiftest result of the weighing process and highest precision of weighing result as our target for every weighing solution we supplied.

With all top-class engineers, we making only high quality weighing terminals, OIML approved load cells, stainless steel scales and precision balances. With high protection till IP68&IP69K, and also multi-output of Modbus, RS232 /RS485, 4-20mA, Bluetooth, WiFi, etc., we can meet almost all your weighing demands.

We are looking for the partners in each market with our win-win policy for the marketing, it's not about selling the products but build up the real long-term business ecosystem!

Moorange - Precise Your Weighing !
HiWEIGH - Value Each Gram !
JoyScale - Enjoy Your Business !

Precise your weighing for industry, laboratory, food, medical and logsitics!
