• Model NO.：BST106-M10[BH]
• Measure Method：Semi-Automatic
• Shell Material：Touch Screen
• Application：Packing,Bagging Weighing
• Certification：CE
• Customized：Customized
• Certificate：CE
• Sampling Frequency：800Hz
• Di&Do：9*Di & 18*Do
• Ao：0-10V * 2
• Communication：RS232&RS485
• IP Grade：IP65
• Power Supply：24V
• Transport Package：Carton Box
• Specification：226.5*163*36mm [W*H*D]
• Trademark：SUPMETER
• Origin：China
• HS Code：8537109090
• Production Capacity：50000PCS,Year

Product DescriptionMain Application:

BST106-M10[BH] is suitable for Increment Ration Packing Scale with optional Single-hopper-weighing Mode, Single-bag-weighing Mode, Double-hopper-weighing with one bag-clamping Mode, Double-hopper-weighing with two bag-clampings Mode and Double-bag-weighing Mode.

Main Features

1. EMC design with high anti-jam for industrial environment.
2. DC24V power input with reverse polarity protection.
3. Cortex-A8 CPU with 600MHz Clock, 128M Flash.
4. 7" [800×480] or 10.2" [1024×600] TFT touch panel.
5. 24-bit ∑-△ADC with internal resolution 1/1,000,000.
6. High sampling frequency 800Hz.

7. Special Anti-vibration Digital Filtering Algorithm for precise weighing, stable display and rapid response.
8. Auto Zero Tracking.
9. Fall Value Auto Correction.

10. Auto Pause for Deviation Alarm.
11. Auto Re-feed for Negative Deviation Alarm.
12. Target Batch Count & Target Batch Weight Control.
13. 3-speed[high/medium/low] feeding control by DOs or AOs.
14. Definable DI/DO/AO/COM[Communication Port].
15. Recipe Number: 100.


Technical Specification:

1. Power Supply: DC24V±20%, Max. 10W.
2. Loadcell Excitation Voltage/Current: DC5V/250mA.
3. 16 Loadcells[350Ω] connectable.
4. Weighing Signal Input Range: 0~12.5mV.
5. 9 Normally Open Switch Inputs [DI].
6. 18 Normally Open Transistor Outputs [DO]: DC24V, 500mA.
7. 2 Analog Signal Outputs [AO]: 0~10V, Max.50mA.
8. COM&COM1: RS232; COM2: RS485.
9. USB1: Connect mouse, software download, data backup.
 LAN: Optional Ethernet.
10. Outline Size [W×H×D]:
        7": 226.5 × 163 × 36 mm.
        10.2": 274 × 193 × 40 mm.
11. Panel Cut-out Size [W×H]
       7": 215 × 152 mm.
       10.2": 261 × 180 mm.
12. Operating Temperature: -25ºC~+45ºC.
13. Protection Level of Front Panel: IP65.
14. Accuracy Grade: III.
15. Verification Accuracy: 0.02%.
16. Static Weighing Accuracy: 0.2%~0.5%.
17. Packing Accuracy: 0.2%~0.5%.
