• Model NO.：BST100-B11+
• Measure Method：Semi-Automatic
• Shell Material：Aluminum
• Application：Conveyor Scale
• Certification：CE
• Customized：Customized
• Excitation Voltage/Max. Current：DC10V,250mA [8-350 Ohm Loadcells]
• Sampling Frequency：400Hz
• Di&Do：3*Di & 4*Do
• Ao：4-20mA * 2
• Communication：RS485 & RS232
• IP Grade：IP65
• Power Supply：AC220V
• Transport Package：Carton Box
• Specification：160*84*188mm [W*H*D]
• Trademark：SUPMETER
• Origin：China
• HS Code：8537109090
• Production Capacity：50000PCS,Year

Product Description

Weighing controller indicator BST100-B11+, Panel mounted controller, is suitable for Ration Belt Weighfeeder with Ration Flow Feeding & Ration Weight Batch Control.

Power SupplyAC220V±15%Display

8+4+4 Red Led Digital Tubes for English&Digit Display

Sampling Frequency400HzA/D Convert24-bitKeypad6 keys for Menu&Shortcut mode operation with key toneExcitation Voltage Output of LoadcellDC10VMax. Connection number of Loadcell8 Loadcells (350Ω)DI3 Normally Open Switch InputsDO4 Normally Open Transistor Switch OutputsAO2'PID Control' Analog Output: 4~20mA.Communication PortCOM1:Optianal RS232/RS485/RS422/Profibus-DP/Ethernet; COM2:RS232Net Weight Approx. 4.2kgIP GradeIP65Accuracy of Flow Control0.5%~1.0%Operatiing Temperature-25ºC~+45ºC

Package:

Packing Details  : Carton Box, 1pcs/box
Delivery Details : 3-30 days after got full paymen


Warranty:

The warranty period for our products is 12 (twelve) months.
If the products from SUPMETER are proved to be unable to work normally due to unartificial reasons, and the problems can't be solved by customers under the technical support from SUPMETER, then customers can send the problematic items back to SUPMETER. SUPMETER is RESPONSIBLE to MEND (or REPLACE when necessary) them FREE OF CHARGE.

(Note: if after checking, the returned goods are proved to be in good condition, the trouble is resulted to be caused by improper operation by customers, SUPMETER is IRRESPONSIBLE to bear the shipping & other charges related to the returning.)


Delivery:

FAQ:


1. What detailed information do I need to provide if I want to place an order?

We need to know the following information: Capacity, Usage and other related parameters you need.



2. Do you have any discount?

Yes, if you buy large QTY, please send us a email, we will give you a big discount.



3. What terms of payment are available?

We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.



4.When will you arrange the production?

We will arrange the production immediately after receiving your payment.



5. How do you ensure good product quality?

We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.
