CATV Analog Digital Signal Level Meter
Hangzhou Softel Optic Co., Ltd.- Type:Dial Indicator
- Material:Plastic
- Measurement Object:Depth
- Range:0~500mm
- Resolution:0.01mm
- Precision:0.015mm
Base Info
- Model NO.:HT8553
- Measure Method:Manual
- Accuracy:B
- Certification:CE
- Customized:Non-Customized
- Item:Signal Level Meter
- Modulation:DVB-C,Itu-T
- Support:64qam,256qam(Option)
- MOQ:1 Piece
- Delivery Time:Around 10 Days
- OEM ODM:Acceptable
- Warranty:12 Months
- Transport Package:Standard Carton
- Specification:ROHS
- Trademark:SOFTEL OEM
- Origin:Zhejiang, China
- HS Code:90318010
- Production Capacity:1000 PCS,Month
Description
Features
Specifications | |
Frequency Range | 5/46MHz~870MHz |
Frequency Resolution | 10KHz |
Frequency Accuracy | ±10x10-6 |
Average Power | 35dBμV~115dBμV |
Power Resolution | 0.1dB |
Power Accuracy | ±2.0dB(under room temperature) |
Input impedance | 75Ω |
MER | 22~39dB |
MER Accuracy | ±2dB |
EVM | √ |
BER | 1E-4~1E-8(after RS) |
Modulation | 16/32/64/128/256QAM |
Constellation Diagram | √ |
