• Model NO.：AS002C
• Operating Environment：Explosion-proof Loadometer
• Signal Output Mode：Wireless and Wired Options
• Display：LED or LCD
• Material：Aluminum-Alloy
• Service：OEM&ODM
• Power Supply：110V , 220V or According to Customer
• Production Time：25~45 Days
• Weighing Capacity：45kg
• Defend Grade：IP66
• Net Weight：1t-40t
• Transport Package：Carton, Wooden Box, Tool Box
• Trademark：SAINTBOND truck axle scale
• Origin：Zhejiang, China
• Production Capacity：8500 Sets Per Month

AS002300×400×56500~8000Kg4pcs LC348 Load Cell,10m Cable
Capacity:500/1000/1500Kg 400×500×561000~10000Kg4pcs LC348 Load Cell,10m Cable
Capacity:1500/2500/3000/5000Kg 450×700×565000~15000Kg6pcs LC348 Load Cell,10m Cable
Capacity:5000/10000/15000Kg 500×900×565000~20000Kg8pcs LC348 Load Cell,10m Cable
Capacity:10000/15000/200000Kg  Product ParametersRated load:1/2/3/5/6/10/20t/weigh padCompensated temp.range: -10~+50ºCDynamic error : 3 (5~10km/h)%F.SStatic error:0.1~0.3%F.SStatic comprehensive error: 0.1~0.5%F.SInsulation resistance: ≥5000MΩ(100VDC)Rated output:1.0±0.1mV/VUse temp.range: -30~+80ºCNon-linearity: 0.2%F.STemp.effect on zero: 0.03F.S/10ºCError on corners: 0.2%F.STemp.effect on span: 0.05F.S/10ºCRepeatariy: 0.05%F.SSafe overload: 120%Zero balance: ±1%F.SUltimate overload: 150%Excitation voltage: 9~15VDCNet weight: 45kgRecommended voltage: 10VDefend grade: IP66
MWI01 Multichannel Weighing Indicator
The Aluminum aviation housing, multi window display
1~4 channel input, axle load, wheel weight, gross weight and percentage weight
The built-in printer, optional rechargeable battery
The RS232/RS485 communication interface

Type	Picture	Description	Housing	Display
MWI01		Multichannel Weighing Indicator Lead acid battery	Flight case	LCD
