Electronic Truck Weighing Scale with Capacity 60t 80t 100t 120t

Quanzhou Wanggong Electronic Scale Co., Ltd.
  • Structure：Mechanical and Electrical Scale
  • Display Type：LED
  • Sensor：Full Scale
  • Installation：Weighbridge
  • Automation：Automation
  • The Weighing Method：Static Truck Scale

Base Info

  • Model NO.：SCS-120
  • Scale Structure：U-Type Steel
  • Operating Environment：Explosion-proof Loadometer
  • Lightning Protection：With Lightning Protection
  • Product Name：Electronic Truck Weighing Scale
  • Accuracy：OIML III
  • Weighing Capacity：60t 80t 100t 120t 150t 200t
  • Division：5kg-50kg
  • Structure of Platform：U Shaped Steel or Concrete
  • Load Cell：Digital or Analogue Are Available
  • Good Quality：Yes
  • U Beams：6 Pieces
  • Transport Package：Standard
  • Specification：3x18m or customized
  • Trademark：Wanggong
  • Origin：China
  • HS Code：8423891090
  • Production Capacity：100000PCS,Year

Description

Load cell interfaceRS485,Max transmission distance≤75mTransmission rateE 19200bps,C 9600bpsPower supplyDC≈12V750mAMax load cell connected1-16pcsDisplay7 bit LED, 7 status indicatorCalendar/clock functionYY/MM/DD, time displayJumbo screen interface20mA, baud rate 600,Transmission distance≤100mSerial communication interfaceRS232, Baud rate 600-19200 optionalPrinter interfaceStandard parallel printing interfaceData storage1500 truck number
201 goods description and model number
100 name of customer
100 remark or notes
2000 weighing recordsIndicator power supplyAC 110-220V,50HzBackup power supplyDC12V/7AhSize303x185x205mm
2. Load Cell
1. MK-40T load cell
2. High precision, stability
3. Digital signal output
4. Good anti-interference ability, signal transmission for a long distance, anti-cheating
5. Self-Diagnostic Function
6. Moisture-proof, adopt to harsh working environment
7. Easy to installation and maintenance
8. Rated load:30t or 40tAccuracyC3Rated load40TRated output0.002%Combined error±0.02%F.STemperature effect on sensitivity±0.02%F.S/10°CTemperature effect on zero balance±0.02%F.S/10°CZero balance±1%F.SInput resistance750±10ΩOutput resistance703±2Ω,703±5Ω(L≥15m)Insulation resistance≥5000mΩSafe overload150%F.SUltimate overload200%F.SWorking temperature(-30~+80)oCRecommend excitation5~18VMax excitation24VMaterial of elastomerAlloy SteelProtection gradeIP67/IP68Cable12.5mTransmission distance800mExecution standardGB/T7551-1997/OIML R60
3. Junction box
  • Stainless steel enclosure is proven protection in harsh environments and against abrasive materials
  • High precision, stability, anti-interference ability
  • Special cable fitting between load cell and signal cable, ensure the good connection
  • Welded wiring or insert wiring are available
4. Printer (optional)
Brand:Panasonic 1131 24-pin bit printer
Feature highlights:
Parameters
Product model: standard pin bit printer
Printing direction: uni-directional/Bi-directional (user selectable)
Pins: 24-pin bit
Head service life:approx 200 million strokes in draft mode
Ink Ribbon:Ink ribbon KX-P145, about 3000,000 character
Replication capability:4pc(1pc original+3pc copies)
Buffer:64KB
Interface:USB2.0,Centronics parallel(IEEE1284 standard)
Printing performance
Printing speed: Draft 240 characters/s,Letter quality 80 character/s
Printing resolution: 360x360dpi
Software emulation: Epson LQ-850,IBM Proprinter X24E
Electronic Truck Weighing Scale with Capacity 60t 80t 100t 120t
Electronic Truck Weighing Scale with Capacity 60t 80t 100t 120t

Our main products include: truck scale, weighbridge, floor scale, bench scale, platform scale, livestock scale, buffer scale, hopper weighing scale, crane scale, belt scale and related weighing instruments.
FAQ
 1.Can you customized the scale design for us?
Yes, we have professional team with rich experience of all type scales design by CAD software.you only need to tell us scale design or send us the technical drawing you want, so that we can customize according to your request.
2.Can you also offer truck scales weighing scales for us?
Yes, we can offer different models of different capacity and size of truck weighing scales to meet different request of customers.
3..How about your weighing scales quality, we are worry about the quality?
We are more than 30 years manufacturing experience of different kinds of electronic truck scales and truck weighing scales.We strictly manufacture and manage according to IOS9001:2000 System.and can match all the CE standard or more strict standard. Our products are running well in more than 30 countries
4.How we visit your factory and what will be the procedure?
Our company located in Quanzhou, FU JIAN province, our nearest airport is JIN JIANG airport, if you take plane, it will need about 1 hours from Guangzhou city, 1.5hours from shanghai and 2 hour from Beijing.We will pick you up from airport as well as the train station.Welcome you and your team to visit us at any time!
5.Your truck scale price is high, is there any discount?
We always provide high quality weighing scales with reasonable prices.Our truck scales have enough quality standard to make sure the scale can work at different sourrounings situations. Our marketing style is quality equal to price, the price will be acceptable for our clients and durable for our productsAnyhow, when we will negotiate the price with each other during our meeting in factory and try our best to get a good satisfaction.
