1.2/50 Hv Surge Impulse Tester Ep Hipot Electric Epdy-B 20kv
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Material：Aluminum Alloy
- Precision：+-3%
- Measure Method：Automatic
- Precision Measuring Device：Precision Measuring Device
Base Info
- Model NO.：EPDY-B20
- Customized：Customized
- Applied Standard：IEC60060-1, -2, IEC61010, IEC 60255-5, -27
- Screen：1280*800 LCD Color Touch Display
- Output DC：0-+-24kv
- Impulse Peak：0-+-24kv
- Position：+-4kv~+-20kv, 1V Step
- Half Peak Time After Wave：50us+-20%
- PC Mode Precision：+-3%
- Automatic Mode Times：1-9999
- Automatic Mode Intervals：5-99s (Default 5s)
- Communication：485-USB
- Manual Mode Impulse Peak Value：+-2~+-20kv
- Manual Mode Interval Time：1-99s
- Breakdown Current Setting Range：30mA-1200mA
- Voltage Attenuation Program：0%-99%
- Environmental Temperature：0-40c
- Transport Package：Plywood Package
- Specification：450mm*380mm*240mm
- Trademark：EP Hipot Electric
- Origin：China
- HS Code：9030899090
- Production Capacity：1000,Year
Description
Environmental Conditions:Environmental temperature: 0-40ºC Environmental humidity: ≤80% Dimensions: 450mm*380mm*240mm Weight: 12kg
More details about 20kV Impulse Voltage Tester EPDY-B20, please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
