• Model NO.：L15BA
• Operating Environment：Explosion-proof Loadometer
• Signal Output Mode：Wireless and Wired Options
• Material：Aluminum-Alloy
• Service：OEM&ODM
• Power Supply：110V , 220V or According to Customer
• Production Time：25~45 Days
• Weighing Capacity：10-15t
• Defend Grade：IP66
• Transport Package：Carton, Wooden Box, Tool Box
• Trademark：SAINTBOND truck axle scale
• Origin：Zhejiang, China
• Production Capacity：8500 Sets Per Month

Basic Info.

Model NO. L15BA Operating Environment Explosion-proof Loadometer Signal Output Mode Wireless and Wired Options Material Aluminum-Alloy Service OEM&ODM Power Supply 110V , 220V or According to Customer Production Time 25~45 Days Weighing Capacity 10-15t Defend Grade IP66 Transport Package Carton, Wooden Box, Tool Box Trademark SAINTBOND truck axle scale Origin Zhejiang, China Production Capacity 8500 Sets Per Month

Product Description

Features:
Light in weight, and convenient transportation;
Integral flat plate construction, high frequency in dynamic response, and high precision;
Adopted special material in aero-industry, with good anti-over loading ability;
Applied special treatment, offering high protection class Ip66, suitable for all kinds of environments;
Completed with rubber approach, easy for loading on/off of the vehicles;
Applications:
Measuring the weight and barycenter of aeroplane;
Measuring weight for special purpose;
Connections: Red lnput(+) Black Input(-) Green Output(+) White Output(-);
Note: Dimension of the approach is 702X330X32;
Dimensions(unit:mm):
Technical Parameter:

Output sensitivity:	0.9±0.2mV/V	Temperature,compensated:	:-10~+50ºC
Combined error:	0.5%ld	Temperature,operating:	:-40~+80ºC
Non-linearity:	0.5%ld	Excitation, recommended:	9~15VDC
Repeatability:	0.1%ld	Excitation,Max.:	20VDC
Creep:	0.1%FS/30min	Safe overload:	120%FS
Input resistance:	3120±40Ω	Ultimate overload:	150%FS
Output resistance:	2800±10Ω	Protection class	IP66
Insulation resistance:	^5000(100VDC)MΩ	Cable Spec.:	4-wire cable
Zero balance:	4~10%FS	Max. load for single point:	10t
Temp. effect on sensitivity:	0.1%FS/10°C	Rated capacity:	15t
Temp.effect on zero:	0.1%FS/10°C
