• Model NO.：JY-10HDSO
• Application：Industrial Scales
• Function：Weighing Scale
• Structure：Electronic Scale
• Shape：Square
• Screen：LED Screen
• Language：11 Languages
• Net Weight：280kg
• Gross Weight：330kg
• Weighing Heads：10 Heads
• Weighing Bucket：2.5L
• Buckets：Smooth Plate or Dimple Plate
• Max Product Length：150mm
• Voltage：110V, 220V, 50,60Hz
• CE：Yes
• Transport Package：by Wooden Cases
• Specification：CE
• Trademark：JNYE
• Origin：Foshan
• HS Code：84233010
• Production Capacity：300sets,Year

Basic Info.

Model NO. JY-10HDSO Application Industrial Scales Function Weighing Scale Structure Electronic Scale Shape Square Screen LED Screen Language 11 Languages Net Weight 280kg Gross Weight 330kg Weighing Heads 10 Heads Weighing Bucket 2.5L Buckets Smooth Plate or Dimple Plate Max Product Length 150mm Voltage 110V, 220V, 50/60Hz CE Yes Transport Package by Wooden Cases Specification CE Trademark JNYE Origin Foshan HS Code 84233010 Production Capacity 300sets/Year

Product Description

This 10 heads multihead weigher with water and dust proof vibration part and the 304 stainless steel main frame (non-water proof)



Optional(different prices):
1. All surfaces in contact with product can be smooth, dimpled or with teflon or electroliticpolishing treatment depending on product.
2. Vibrating pans can be inclinated.
3. Collating chute can be more or less inclinated.
4. Top cone can be with rotating motor.

Collect Bucket:
This optional bucket collects the product at end of the bottom funnel and drops carefully to the bagger avoiding product dispersion and mistreating.


Use range:
Dry & processed foods, fresh foods. For example: Sank foods, seeds (pulses), Coffee(granules/beans), Tea, Sugar, Grated Chess, Bakery Products, Candies & Confectionery, Rice, Nuts & Dried Fruits, Spices, small Pasta pieces, Pet Food(pellets) etc.

Other: Non Food srews, nails, buttons, rivets, bar items, plastic parts, metal parts...
For example: Small - Nuts, Bolts, Washers, Auto, Electrical and Plumbing Parts etc.
All parts contact food are stainless steel.

Features:
All food contacted surface is made of Stainless Steel, all parts are enclosed to prevent product build-up.
Speed adjustment of hopper movement by step motor, no air consumption
Statistical Data-Inspect on screen and via optional printer output;
Optional language of operation. English, Japanese, Chinese, Italian, German, Spanish, Russian etc.
Options: Dimpled plate on all product contact surfaces, Overweight discharge equipment, Collection hopper, Printer.

Net weight: 260kg, gross weight: 300kg
Packing size: 108X108X125cm


Technical:
Each dump weighing range 8-1000g
Combination capacity Max 3000ml
Highest speed 60 bags/min
Length of material Max 150mm
Each bag error 0.1-1g
Weighing accuracy 0.1-1g
Mode of driving Step motor
Form of dipper Double-row non-memory dippers
Preset function Max 50 choices
Material The part contacting materials is made of 304 stainless steel
Level control Photoelectricity(pass type)
Power source AC200/220V± 10% 1.5kVA
Dimension 950(L) * 950(W) *1000(H)mm

1. Humidity: 35-85% (there should be no condensation)
2. Password: The password system can be provided to protect the important parameters from tampering yb unauthorized person. The menu system is divided into three groups: Operator Level, Supervisor Level and Engineer Level.
3. The clean out procedure is used to discharge all the product left on the cross-head feeder and the machine before changing product or at the end of daily production.
4. If a bucket has trouble, such as ZERO ERROR, SPAN ERROR or ACTUATOR ERROR, you can inhibit the bucket and continue the operation of the system suing the rest of the heads(buckets).
5. Counting mode: If the products are almost the same size and the same weight in piece, and you want the exact number piecs in each bag, use this function
6. Over discharge: A combination exceeding the High limit can be discharge when this set to "ON".
7. AUTO ZERO INTERVAL: This used to set interval automatic zero reseting in min.
8. Discharging in turn: This function used to weigh the easy break or fragile products, so that the products will not drop all together to hit each other. That is the bucket will discharge the weighed products one by one.
