• Model NO.：V22PW
• Material：Stainless Steel
• Measure Method：Automatic
• Application：Industrial Scales, Commercial Scale
• Function：Weighing Scale, Counting Scales
• Structure：Electronic Scale
• Shape：Square
• Transport Package：Carton
• Specification：LED, dual display
• Trademark：Ohaus
• Origin：China
• HS Code：84238190
• Production Capacity：10000PCS,Month

1: 6,000 / 1:7,500

Weighing Units

V22PW: g / lb **
V22XW: g, kg, lb, oz, lb:oz

Application Modes

V22PW: Weighing
V22XW: Weighing, Checkweighing

Keyboard

V22PW: Two mechanical switches with polycarbonate overlay
V22XW: Four mechanical switches with polycarbonate overlay

Calibration

Digital external span calibration

Display

7 segment, 6 digital / 20.5 mm high red LED, dual display

Display Indicators

Stability, center of zero, net, battery status

Tare Range

To capacity by subtraction

Zero Range

4% - 20% of Capacity

Stabilization Time

≤0.5 second

Overload Capacity

150% of capacity

Operating Temperature Range

-10 º C to 40 º C, 10% to 90%
relative humidity non-condensing

Construction

V22PW: Stainless steel platform, ABS housing
V22XW: Stainless steel platform and housing

Power

12V DC 0.84A, AC Universal adapter (100-220V AC / 50-60Hz) included

Battery Life

Internal rechargeable sealed lead-acid battery with 50 hours continuous use

Ingress Protection

IPX8 Water in water out

Platform Size

190 × 242 mm

Scale Dimensions (W × D × H)

V22PW: 280 × 256 × 121 mm
V22XW: 288 × 256 × 124 mm

Shipping Dimensions
(W × D × H)

410 × 370 × 220 mm

Net Weight

V22PW: 3.0 kg
V22XW: 3.9 kg

Shipping Weight

V22PW: 4.0 kg
V22XW: 4.9 kg
