Digital Measuring Profile Projector (JT3-D JT3-C: 500mm, 200mm*100mm)
Guiyang Xintian Oetech Co., Ltd.- Type:Dial Indicator
- Material:Iron
- Measurement Object:dimensions
- Range:0~500mm
- Resolution:0.001mm
- Precision:0.001mm
Base Info
- Model NO.:JT3-D JT3-C
- Accuracy:(4+L,25) micron
- Precision Measuring Device:Precision Measuring Device
- Certification:GB, CE, ISO
- Customized:Non-Customized
- Screen Diameter, Stage Travel(X*Y):500mm, 200mm*100mm
- Transport Package:Veneer Case
- Specification:ISO9001: 2000 CE Certificate
- Trademark:SINPO FOIC CHFOIC
- Origin:Guizhou, China
- HS Code:9031491000
- Production Capacity:2000 Units,Year
Description
Basic Info.
Model NO. JT3-D JT3-C Accuracy (4+L/25) micron Precision Measuring Device Precision Measuring Device Certification GB, CE, ISO Customized Non-Customized Screen Diameter, Stage Travel(X*Y) 500mm, 200mm*100mm Transport Package Veneer Case Specification ISO9001: 2000 CE Certificate Trademark SINPO FOIC CHFOIC Origin Guizhou, China HS Code 9031491000 Production Capacity 2000 Units/YearProduct Description
Features:JT3-Dφ 500 digital measuring projector
JT3-Cφ 500 data processing projector
Characteristics
A high-accurate objective rotary disc is very convenient for the transformation of magnification and the precise positioning;
The internal focusing transmission illuminating system has a compact structure The installed accessories of tailstock, V-type support, etc. Is very convenient for the measurements of various shaft-like parts;
The JT3-D type is equipped with a digital readout of full and complete function; The JT3-C type is equipped with a computer and data processing software.
Usages:
Technical parameters:
Technical Parameters
Projection screen
Projection screen: φ 500 mm
Rotation range: 360°
Worktable
Worktable area (mm): 640× 228
Load capacity of the worktable: 15kg
Measuring range (mm)
X-coordinate: 200 Y-coordinate: 100 Z-shaft (focusing): 80
Resolution: 0.001mm
Accuracy of the instrument: (4+L/25)μ M, of which, L = length of the workpiece measured ( unit: Mm)
Tailstock rack
Maximum diameter gripped: Φ 115mm
Maximum length gripped: 300mm
Lighting source
Transmission lighting: 12V 100W Halogen tungsten lamp
Reflecting lighting: 12V 100W Halogen tungsten lamp
Objective
Magnification Power: 10× , 20× , 50× , 100×
Object Visual Field; φ 50mm, φ 25mm, φ 10mm, φ 5mm
Object Working Distance: 135mm, 87mm, 52mm, 24mm
Errors of magnifying power: 0.08%
Overall sizes of the instrument (mm): 1340× 800× 1960
Mainframe weight: 1000kg
Model | JT3-D | JT3-C |
Projection Screen | φ500mm | φ500mm |
Rotation Range | 0°~360° | 0°~360° |
Resolution of the rotary angle | 1′ | |
Rotation division value of projection screen | 1° | |
Objective Magnification Power | 10X 20X 50X 100X | 10X 20X 50X 100X |
Objective Visual Field | φ50mm φ25mm φ10mm φ5mm | φ50mm φ25mm φ10mm φ5mm |
Objective Working Distance | 135mm 87mm 52mm 24mm | 135mm 87mm 52mm 24mm |
Error of magnification | 0.08% | 0.08% |
Range of X-coordinate (mm) | 200mm | 200mm |
Range of Y-coordinate (mm) | 100mm | 100mm |
Z -coordinate (Focusing)(mm) | 80mm | 80mm |
Worktable area | 640mm×228mm | 640mm×228mm |
Resolution | 0.001mm | 0.001mm |
Image | Reverse | Reverse |
Accuracy of Instrument | (4+L/25)μm | (4+L/25)μm |
Load Capacity | 15kg | 15kg |
Overall Size(mm) | 1340×800×1960 | 1340×800×1960 |
Transmission Lighting | 12V 100W Halogen tungsten lamp | 12V 100W Halogen tungsten lamp |
Reflecting Lighting | 12V 100W Halogen tungsten lamp | 12V 100W Halogen tungsten lamp |
Rated Voltage | ||
Mainframe Weight | 1000kg | 1000kg |
Tailstock rack | Max diameter φ115mm | Max diameter φ115mm |
Tailstock rack | Max length φ300mm | Max length φ300mm |
