• Model NO.：KM-3302-1300
• Precision Measuring Device：Precision Measuring Device
• Certification：DIN, GB, RoHS, ISO
• Customized：Customized
• Measurement：Metric
• Transport Package：Wood Box
• Specification：GB Standard
• Trademark：KM
• Origin：Shaanxi, China
• HS Code：9017300000
• Production Capacity：50000pieces,Month

Basic Info.

Model NO. KM-3302-1300 Precision Measuring Device Precision Measuring Device Certification DIN, GB, RoHS, ISO Customized Customized Measurement Metric Transport Package Wood Box Specification GB Standard Trademark KM Origin Shaanxi, China HS Code 9017300000 Production Capacity 50000pieces/Month

Product Description

Feature:
1. Graduation:0.01mm(Metric);0.001''(Inch).
2. The combining of extension rods provides a wide measuring range.
3. Carbide measuring faces.
4 .Diameter of extension rods:φ22mm.
5. Accuracy:(3+n+L/50)μm(Metric);[0.00005(3+n+L/2)](Inch);
(n=number of rod, L=maximum measuring length(mm) [Inch]).

Specification:
Metric

Order No.	Measuring Range	Extension Rods
KM-3302-125	100~125mm	Micrometer head
KM-3302-500	100~500mm	25mm,50mm,100mm,200mm
KM-3302-900	100~900mm	25mm,50mm,100mm,200mm,400mm
KM-3302-1300	100~1300mm	25mm,50mm,100mm,200mm,400mm(2pcs)
KM-3302-1700	100~1700mm	25mm,50mm,100mm,200mm,400mm(3pcs)
KM-3302-2100	100~2100mm	25mm,50mm,100mm,200mm,400mm(4pcs)

Inch

Order No.	Measuring Range	Extension Rods
KM-3302-5	4-5″	Micrometer head
KM-3302-20	4-20″	1″, 2″, 4″, 8″
KM-3302-36	4-36″	1″, 2″, 4″, 8″, 16″
KM-3302-52	4-52″	1″, 2″, 4″, 8″, 16″(2pcs)
KM-3302-68	4-68″	1″, 2″, 4″, 8″, 16″(3pcs)
KM-3302-84	4-84″	1″, 2″, 4″, 8″, 16″(4pcs)
