• Model NO.：KM-600SC
• Measure Method：Manual
• Precision Measuring Device：Precision Measuring Device
• Certification：DIN, GB, RoHS, ISO
• Customized：Customized
• Measurement：Metric
• Transport Package：ABS Box
• Specification：GB Standard
• Trademark：KM
• Origin：Shaanxi, China
• HS Code：9017300000
• Production Capacity：50000pieces,Month

Basic Info.

Model NO. KM-600SC Measure Method Manual Precision Measuring Device Precision Measuring Device Certification DIN, GB, RoHS, ISO Customized Customized Measurement Metric Transport Package ABS Box Specification GB Standard Trademark KM Origin Shaanxi, China HS Code 9017300000 Production Capacity 50000pieces/Month

Product Description

Feature:
1. Outside diameter (O.D),inside diameter (I.D)and steps measuring.
2. Lock screw.
3. open and close type available.
4. Long jaws for measuring hard to reach positions.
5. Fine adjustable.

Specification:

Order No.	Measuring Range	Accuracy	Graduation
KM-500SC	0~500mm	±0.05mm	0.02mm
KM-600SC	0~600mm	±0.05mm	0.02mm
KM-1000SC	0~1000mm	±0.07mm	0.02mm
KM-1500SC	0~1500mm	±0.11mm	0.02mm
