• Model NO.：LK300 for thickness gauge
• Usage：For Inspection
• Shape：Rectangular
• Customized：Non-Customized
• Display Method：High-Contrast LCD Display ,High-Bright
• Measurement Range：(0.75 ~ 300) Mm (Steel)
• Sound Velocity Range：(1000 ~ 9999) M , S
• Resolution：0.1mm,0.01mm Optional
• Indication Accuracy：+,- (0.5% H +0.05) Mm
• Measuring Cycle：Single-Point Measurements Per Second Four Times
• Storage Capacity：Store 20 Groups (Each up to 100 Measurements) Thic
• Unit System：Metric or Imperial (Optional)
• Operating Voltage：3V (2 Alkaline Batteries)
• Continuous Working Time：More Than 100h (Not Open Backlight Pm)
• Transport Package：carton
• Specification：Lk300
• Trademark：suxing
• Origin：China
• Production Capacity：500000PCS,Year

Basic Info.

Model NO. LK300 for thickness gauge Usage For Inspection Shape Rectangular Customized Non-Customized Display Method High-Contrast LCD Display ,High-Bright Measurement Range (0.75 ~ 300) Mm (Steel) Sound Velocity Range (1000 ~ 9999) M / S Resolution 0.1mm/0.01mm Optional Indication Accuracy +/- (0.5% H +0.05) Mm Measuring Cycle Single-Point Measurements Per Second Four Times Storage Capacity Store 20 Groups (Each up to 100 Measurements) Thic Unit System Metric or Imperial (Optional) Operating Voltage 3V (2 Alkaline Batteries) Continuous Working Time More Than 100h (Not Open Backlight Pm) Transport Package carton Specification Lk300 Trademark suxing Origin China Production Capacity 500000PCS/Year

Product Description

thickness gauge
Industrial thickness gauge



1. Suitable for measuring metal (such as steel, cast iron, aluminum, copper, etc. ), plastic, ceramic, glass, glass fiber and other any good conductors of ultrasonic thickness.
2. Can be equipped with different frequencies, different sizes of crystal double probe usage.
3. With probe zero calibration and two calibration function, can automatic correct the system error.
4. The known thickness can set back sound velocity, in order to improve the accuracy of measurement.
5. Coupled state with prompt functions.
6. With EL backlit, convenient in use in dim light.
7. With dump energy instruction function, can real-time display battery remaining power.
8. Auto dormancy, shutdown and auto power etc. Saving function.
9. With RS232 interface and can easily and quickly exchange data with PC. Can be connected to the micro printer (manufacturer designated models) print measurement the reports.
10. Can choose equipped with computer software, with measured results, measured storage management, measured statistical analysis values, printing measured report etc. Rich functions.
11. Small, portable, high reliability, applicable to the severe operating environment like anti-vibration, anti-shock and electromagnetic interference (EMI).
