• Model NO.：IMS2515
• Measure Method：Manual
• Accuracy：A
• Precision Measuring Device：Precision Measuring Device
• Certification：ISO
• Customized：Customized
• Transport Package：Plywood
• Specification：790*617*1000mm
• Trademark：SINOWON
• Origin：Donguan, China
• HS Code：9024102000
• Production Capacity：30 Sets,Month

IMS-2515Code#521-150Metal Table408x308mmGlass Table306x198mmX/Y-axis Travel250x150mmZ-axis TravelHigh-precision linear guide, working travel 200mmX/Y/Z-axis Travel0.0005mmX/Y-axis Accuracy≤2.5+L/200(um)Hysterisis Error2umBase and PillarHigh Accuracy Jinan Qing MarbleIllumination System(Software Adjustment)Surface:Stepless Adjustable 4-ring 8-division LED Cold IlluminationContour:LED Parallel IlluminationLED Laser Navigation LightsCCD CameraHigh Resolution 700TV Color CCD CameraZoom lens6.5X High Resolution Detented Zoom LensMagnification:0.7X~4.5X;Video Magnification:26X~172XWorking EnvironmentTemperature:20ºC±2ºC, change range < 2ºC/hrHumidity:30% ~80%RHVibration<0.002g, <15HzMeasuring SoftwareIMeasuring 2.1Operation SystemSupport XP, WIN7, WIN8.1, WIN 10, 32/64 operating systemLanguageEnglish, Simplified Chinese, Traditional Chinese, other language versions can be addedDimension(W*D*H)790x617x1000mmNet Weight175Kg
Recommend model:

IMS-2010 521-140; 200x100mm
IMS-3020 521-160; 300x200mm
IMS-4030 521-170; 400x300mm
IMS-5040 521-180; 500X400mm



Standard Delivery:

Product Name	Code#	Product Name	Code#
2.5D Measuring Software	IM2.1	Video Capture Card	527-130
Contour LED Parallel Illumination	425-100	DELL PC System	581-960
Surface 4R/8D LED Illumination	425-130	AV Video Cable	581-940
Laser Positioning System	581-330	RS232 Data Cable	581-930
Detented Zoom Lens	421-100	Optical Calibration Block	581-800
HD700TVL Color Camera	484-130	Operation Manual	/
