• Model NO.：JT36-500 JT36-600
• Accuracy：(4+40,L) micrometer
• Certification：GB, CE, ISO
• Customized：Non-Customized
• Screen Diameter：600mm
• Stage Travel(X*Y)：200mm*100mm
• Weight：550kg
• Transport Package：Veneer Case
• Specification：ISO9001: 2000 CE Certificate
• Trademark：Sinpo
• Origin：Guizhou, China
• HS Code：9031491000
• Production Capacity：200 Units,Year

Basic Info.

Model NO. JT36-500 JT36-600 Accuracy (4+40/L) micrometer Certification GB, CE, ISO Customized Non-Customized Screen Diameter 600mm Stage Travel(X*Y) 200mm*100mm Weight 550kg Transport Package Veneer Case Specification ISO9001: 2000 CE Certificate Trademark Sinpo Origin Guizhou, China HS Code 9031491000 Production Capacity 200 Units/Year

Product Description

Features:

JT36φ 500 Vertical Projector
JT36φ 600 Vertical Projector
Characteristics
The projection screen of the instrument is vertically installed, convenient for the user to observe.
The standard configurations of the instrument are 10× Objectives, And the 5× Objectives, 20× Objectives, 50× Objectives, 100× Objectives, can be selected according to user's requirement.
Large worktable can be customized according to user's requirements.

Specification and Parameter:
Projection screen (JT36-500):
Screen diameter(mm): φ 500
Rotation range: 0° ~360°
Resolution of the rotary angle: 1
Accuracy of the rotary angle: 6

Projection screen (JT36-600):
Screen diameter(mm): φ 600
Rotation range: 0° ~360°
Resolution of the rotary angle: 1
Accuracy of the rotary angle: 6

Objective (JT36-500)
Objective Magnification: 5× , 10× , 20× , 50× , 100×
Object Visual Field: φ 100mm, φ 50mm, φ 25mm, φ 10mm, φ 5mm
Object Working Distance: 102mm, 77mm, 87mm, 76.6mm, 49mm

Objective (JT36-600)
Objective Magnification: 5× , 10× , 20× , 50× , 100×
Object Visual Field: φ 120mm, φ 60mm, φ 30mm, φ 12mm, φ 6mm
Object Working Distance: 102mm, 77mm, 87mm, 76.6mm, 49mm

Worktable:
Worktable area(mm): 500× 260
Load capacity of the worktable: ≤ 10
Measuning range(mm): X-coordinate200, Resolution 0.001
Y-coordinate100, Resolution 0.001
Z-shaft(Focusing): 80
Accuracy of the instrument: (4+40L)μ M, of which, L = length of the workpiece measured ( unit: M)
Large worktable:
Worktable area(mm): 600× 360
Load capacity of the worktable: ≤ 5
Measuning range(mm):
X-coordinate300, Resolution 0.001
Y-coordinate200, Resolution 0.00
Z-shaft(Focusing): 80
Accuracy of the instrument: (4+40L)μ M, of which, L = length of the workpiece measured ( unit: M)
Lighting source:
Transmission lighting: 12V 150W Halogen tungsten lamp
Reflecting lighting: 12V 150W Halogen tungsten lamp
Overall sizes of the instrument (mm): 1420 × 1300× 1940
Mainframe weight(kg): JT36(500): 500, JT36(600)550
Remarks on the power source: 220V 50Hz
Room temperature: 20° C± 5° C
Relative humidity: Not more than 60%

Model	JT36-500	JT36-600
Projection Screen	φ500mm	φ600mm
Rotation Range	0°~360°	0°~360°
Resolution of the rotary angle	1′	1′
Accuracy of the rotary angle	6′	6′
Objective Magnification Power	5X     10X     20X    50X    100X	5X     10X    20X    50X    100X
Objective Visual Field	φ100mm φ50mm φ25mm  φ10mm  φ5mm	φ120mm φ60mm φ30mm  φ12mm  φ6mm
Objective Working Distance	102mm   77mm   87mm    76.6mm   49mm	102mm   77mm   87mm    76.6mm   49mm
Error of magnification
Range of X-coordinate (mm)	200mm	300mm
Range of Y-coordinate (mm)	100mm	200mm
Z -coordinate (Focusing)(mm)	80mm	80mm
Worktable area	500mm×260mm	600mm×360mm
Resolution	0.001mm	0.001mm
Image	Reverse	Reverse
Accuracy of Instrument	(4+L/40)μm	(4+L/40)μm
Load Capacity	10kg	5kg
Overall Size(mm)	1420×1300×1940	1420×1300×1940
Transmission Lighting	12V 150W Halogen tungsten lamp	12V 150W Halogen tungsten lamp
Reflecting Lighting	12V 150W Halogen tungsten lamp	12V 150W Halogen tungsten lamp
Rated Voltage	220V  50Hz	220V  50Hz
Mainframe Weight	500kg	550kg
