• Model NO.：KM-2132-100
• Precision Measuring Device：Precision Measuring Device
• Certification：DIN, GB, RoHS, ISO
• Customized：Customized
• Measurement：Metric
• Protection Degree：IP54
• Transport Package：ABS Box
• Specification：DIN Standard
• Trademark：KM
• Origin：Shaanxi, China
• HS Code：9017300000
• Production Capacity：50000pieces,Month

Basic Info.

Model NO. KM-2132-100 Precision Measuring Device Precision Measuring Device Certification DIN, GB, RoHS, ISO Customized Customized Measurement Metric Protection Degree IP54 Transport Package ABS Box Specification DIN Standard Trademark KM Origin Shaanxi, China HS Code 9017300000 Production Capacity 50000pieces/Month

Product Description

Feature:
1.Resolution:0.001mm(Metric);0.00005''(Inch).
2. Large LCD for easy reading.
3. IP54 protection degree.
4. Display data is origin data of absolute measurement after changing battery.
5. Chrome-plated or painted frame.
6. Carbide measuring faces.
7. Criterion:DIN863/1, DIN40050/IEC529.
8. Supplied in the storage case.

Specification:
Metric/Inch:

Order No.	Measuring Range	Accuracy	Resolution
KM-2132-25	0-25mm/0-1"	±0.002mm	0.001mm
KM-2132-50	25-50mm/1-2"	±0.002mm	0.001mm
KM-2132-75	50-75mm/2-3"	±0.003mm	0.001mm
KM-2132-100	75-100mm/3-4"	±0.003mm	0.001mm
KM-2132-125	100-125mm/4-5"	±0.003mm	0.001mm
KM-2132-150	125-150mm/5-6"	±0.003mm	0.001mm
KM-2132-175	150-175mm/6-7"	±0.004mm	0.001mm
KM-2132-200	175-200mm/7-8"	±0.004mm	0.001mm

Inch/Metric:

Order No.	Measuring Range	Accuracy	Resolution
KM-2132-1	0-1"/0-25mm	±0.00008"	0.00005"
KM-2132-2	1-2"/25-50mm	±0.00008"	0.00005"
KM-2132-3	2-3"/50-75mm	±0.00012"	0.00005"
KM-2132-4	3-4"/75-100mm	±0.00012"	0.00005"
KM-2132-5	4-5"/100-125mm	±0.00012"	0.00005"
KM-2132-6	5-6"/125-150mm	±0.00012"	0.00005"
KM-2132-7	6-7"/150-175mm	±0.00016"	0.00005"
KM-2132-8	7-8"/175-200mm	±0.00016"	0.00005"
