• Model NO.：XK315A1GB-LF
• Application：Electronic Platform Scale and Weighing Scale
• Certification：OIML, Ce
• Customized：Customized
• Screen：6-Digit 25.4mm LCD
• Material：Stainless Steel Housing
• Power：6V 4ah Battery
• Protection Class：IP66 Waterproof
• Transport Package：Standard Carton Packing
• Specification：260*222*161mm
• Trademark：CAISUN
• Origin：China
• HS Code：8423900010
• Production Capacity：30000PCS,Year

Basic Info.

Model NO. XK315A1GB-LF Application Electronic Platform Scale and Weighing Scale Certification OIML, Ce Customized Customized Screen 6-Digit 25.4mm LCD Material Stainless Steel Housing Power 6V 4ah Battery Protection Class IP66 Waterproof Transport Package Standard Carton Packing Specification 260*222*161mm Trademark CAISUN Origin China HS Code 8423900010 Production Capacity 30000PCS/Year

Product Description

Water proof weighing indicator with stainless steel housing(XK315A1GB-LF)

1.Basic information

Model:XK315A1GB-LF
Stainless steel housing
6-digit 25.4mm LCD
Dimensions:265×222×161mm
Applications:Electronic platform scale, weighing scale, etc.
PACKAGE
Quantity:12 PCS per Carton
Dimension:48x59x60cm
Weight:About 25 kg

2. Functions and Features

1.Operating temperature: 0ºC to 40ºC2.Storage temperature: -25ºC to 55ºC3.Relative humidity:≤ 85% non-condensing4.30 hours of full charge battery operation5.Drive up 4X350Ω or 8X700Ω load cell6.Manual/Automatic accumulation7.Programmable zero tracking8.Programmable digital filter9.Selectable kg and lb10.RS-232 serial interface11.Optional RS485 serial interface12.Accuracy can be increased ten times13.Animal weighing14.Hold function15.Counting function16.Printer17.LO-OK-HI set point 18. Power: 6V 4A battery

3. Optional

RS232/RS485 serial interface
Mechanical scale

This indicator could be used for weighing scales like electric platform scales, hopper scales or other weighing scales. We also could use it for force measurement and industry progress controlling. bransensor.en.made-in-china.com
