Stainless Steel Load Cell Junction Box for Weighing Scale (BJCSS014A)

Hefei Brans Measuring And Controlling Technology Co., Ltd.
  • Material：Stainless Steel
  • Potentiometer：USA Bourns
  • Channels：2, 4, 6, 8, 10, 12, 14 Channels
  • Application：Weighing Scales
  • Terminals：Spring Clamp Screwless
  • Sealed Joints：Plastic Joints

Base Info

  • Model NO.：BJCSS014A
  • Transport Package：Exporting Cartons
  • Specification：252*173*46mm
  • Trademark：BRANS
  • Origin：China
  • HS Code：8536300000
  • Production Capacity：100000pieces,Day

Description

NUMBERITEMDETAILS1Model bumberBJCSS014A2Connection versions2,4,6,8,10,12,143Material of housingStainless steel4Circuit Boardwith anti-fungal coating5PotentiometersBOURNS-3296, 100Kohms, 25-turn cermet6Connect TerminalsSpring clamp screwless, 12-28 AWG7Sealed JointsPlastic material joints8TrimmingIndividual cell, signal trim9EnclosureStainless Steel NEMA Type10Protection ClassIP6511Size252*173*46mm(L*W*H)12WarrantyOne-year limited warrantyStainless Steel Load Cell Junction Box for Weighing Scale (BJCSS014A)

5. Applications
Universal applications in weighing machinery, Process Weighing, weighing scales like Truck scales, tank and silo weighing systems, test & measurement and process automation and control sectors which Commonly used in multi-load cell weighing applications

6. Relevant industries: Weighing Machinery, Process Weighing, Process Automation + Control
   Test + Measurement

All of these junction boxes can be customized with Aluminium (A), polyester (P) or stainless steel (E) housing. Welcome to Brans and talk about it.
