• Model NO.：LP7561
• Application：Heavy Industrial
• Certification：ISO
• Customized：Customized
• Type：Weighing Indicator
• Display：6-Digit 25mm LCD with Backlight
• Key：8
• Power Supply：AC110V~240V 50,60Hz
• Battery Enduring Life：30 Hours
• Communication：Zigbee 2.4GHz
• Distance：80m
• Transmitter：Lp7562W,Lp7562V (6 at Most)
• Operating Temperature：-10ºC ~ +40ºC (14ºF~104ºF)
• Rated Load：100000kg
• Input Sensitivity：0.5μV,D
• Zero Tracking：0.5 D,S
• Excitation：DC5V
• Input Voltage：-30mv~30mv
• Transport Package：Carton
• Trademark：LOCOSC
• Origin：China (Mainland)
• HS Code：9031809090
• Production Capacity：50000PCS,Years

Basic Info.

Model NO. LP7561 Application Heavy Industrial Certification ISO Customized Customized Type Weighing Indicator Display 6-Digit 25mm LCD with Backlight Key 8 Power Supply AC110V~240V 50/60Hz Battery Enduring Life 30 Hours Communication Zigbee 2.4GHz Distance 80m Transmitter Lp7562W/Lp7562V (6 at Most) Operating Temperature -10ºC ~ +40ºC (14ºF~104ºF) Rated Load 100000kg Input Sensitivity 0.5μV/D Zero Tracking 0.5 D/S Excitation DC5V Input Voltage -30mv~30mv Transport Package Carton Trademark LOCOSC Origin China (Mainland) HS Code 9031809090 Production Capacity 50000PCS/Years

Product Description

LOCOSC LP7561 Weighing Indicator


New, highly featured axle indicators give the range and flexibility to produce the weighing system to suit your application.

Technical parameters:

Display	6-digit 25mm LCD with backlight
Key	8
Power supply	AC 110V~240V 50/60Hz, 6V4Ah lead acid battery
Battery enduring life	30 hours
Communication	Zigbee 2.4GHz
Distance	80m
Transmitter	LP7562W/LP7562V (6 at most)
Operating temperature	-10ºC ~ +40ºC
Input sensitivity	0.5μV/D
Load cell excitation	DC5V, maximum connect with 24 pcs of 350Ω load cell
Zero calibration	-30mV ~ 30mV
AD internal resolution	1/2000000
AD external resolution	1/15000
AD coversion rate	60 times/sec
Span calibration	Full digital calibration
Dimension	200mm* 75mm* 185mm
Weight	1.8kg

Features:
1. high resolution axle indicator;
2. it can connect with 1/2/3/4 weighing pads;
3. 6-wire or 4-wire loadcell support, maxim 24pcs of load cells;
4. serial port RS232;
5. PC command mode;
6. stainless steel bracket.














We are a manufacturer of weighing apparatus and high precision instruments for professional use. From high precision micro-analysis to more than 100 tons of weighing application, we specialize our products and solutions around various processes of the petrochemical, metallurgical, chemical, port, building material, breeding, paper making, pharmaceutical, food, textile, and logistics industry. Main products: electronic weighing scale (bench scale, floor scale, platform scale, crane scale, animal scale, pallet truck scale), digital weighing indicator, load cell, sensor, weighing module, etc.










Adhering to the business philosophy of "Modular craft, Pipelining production, Integrated brand, Global service", LOCOSC Precision is a group company responsible for the research and development, manufacturing, solutions, sales and after-sales services of weighing equipment. We are headquartered in Ningbo and have branches in Shanghai, Guangzhou, Zhengzhou, Beijing, Chengdu, Qingdao, America. We have more than 500 employees and a factory area of 23, 000 square meters.

At present, the annual production and sales capacity of LOCOSC is 30, 000 bench scales, 30, 000 floor scales, 4, 000 truck scales, 200, 000 weighing indicators, 500, 000 load cells, 20, 000 crane scales, 20, 000 platform scales, 500 loader scales, and more than 100 weighing systems. Each product of LOCOSC has its uniqueness and has been awarded many certifications, such as ISO9001, NTEP, OIML, CE.

Our products have been well sold all over China, and 60% of them are exported to North America, Europe, South America, Southeast Asia. Besides, LOCOSC is an experienced company for ODM & OEM service. We have cooperation with well-known enterprises both at home and abroad. We owe our achievement to your trust and the driving force for self-transcendence. We promise to improve performance and reduce costs with abundant energy and passion.
