• Model NO.：KM-3303-1500
• Precision Measuring Device：Precision Measuring Device
• Certification：DIN, GB, RoHS, ISO
• Customized：Customized
• Measurement：Metric
• Transport Package：Wood Box
• Specification：GB Standard
• Trademark：KM
• Origin：Shaanxi, China
• HS Code：9017300000
• Production Capacity：50000pieces,Month

Basic Info.

Model NO. KM-3303-1500 Precision Measuring Device Precision Measuring Device Certification DIN, GB, RoHS, ISO Customized Customized Measurement Metric Transport Package Wood Box Specification GB Standard Trademark KM Origin Shaanxi, China HS Code 9017300000 Production Capacity 50000pieces/Month

Product Description

Feature:
1.Graduation:0.01mm(Metric);0.001″(Inch).
2.The combining of extension rods provides a wide measuring range.
3.Supplied with a standard caliper gage for zero setting.
4.Diameter of extension rods:φ22mm.
5.Accuracy: (3+n+L/50)μm (n=number of rod,L=max measuring length(mm)).

Specification:
Metric

Order No.	Measuring Range	Extension Rods
KM-3303-175	150~175mm	Micrometer Head
KM-3303-1400	150~1400mm	25mm,50mm(2pcs),100mm,200mm,400mm(2pcs)
KM-3303-1500	150~1500mm	25mm,50mm(2pcs),100mm(2pcs),200mm,400mm(2pcs)
KM-3303-2000	150~2000mm	25mm,50mm(2pcs),100mm,200mm(2pcs),400mm(3pcs)
KM-3303-2100	150~2100mm	25mm,50mm(2pcs),100mm(2pcs),200mm(2pcs),400mm(3pcs)

Inch

Order No.	Measuring Range	Extension Rods
KM-3303-7	6~7″	Micrometer Head
KM-3303-56	6~56″	1″,2″(2pcs),4″,8″,16″(2pcs)
KM-3303-60	6~60″	1″,2″(2pcs),4″(2pcs),8″,16″(2pcs)
KM-3303-80	6~80″	1″,2″(2pcs),4″,8″(2pcs),16″(3pcs)
KM-3303-84	6~84″	1″,2″(2pcs),4″(2pcs),8″(2pcs),16″(3pcs)
