Suzhou Foif Automatic Level Dsz
Nanjing Hanzhong Mapping Equipment Co., Ltd.- Type：Dial Indicator
- Material：High-speed Steel
- Precision：0.02mm
- Measure Method：Automatic
- Precision Measuring Device：Precision Measuring Device
- Certification：ISO
Base Info
- Model NO.：DSZ
- Language：English
- Transport Package：Carton
- Specification：SE SGS
- Production Capacity：100,Month
Description
Basic Info.
Model NO. DSZ Language English Transport Package Carton Specification SE SGS Production Capacity 100/MonthProduct Description
Magnification 32X Accurate Auto Level (DS32-L)- Magnification 32X Accurate Auto Level (DS32S)
- Magnification 32X Accurate Auto Level (DS32H)
Product Details
Basic Info.
Model NO.:DSC132Accuracy:+/- 0.5′ ′Offset:1mmGrade:ProfessionalImage:ErectMagnification:32XExport Markets:South America, Mid East, Eastern Asia, Western EuropeAdditional Info.
Trademark:PRO LEVELPacking:ABS Carrying CaseStandard:CEOrigin:ChinaProduction Capacity:Large QuantityProduct Description
Profession and Accurate Automatic Level DSC132Specifications of Profession and Accurate Automatic Level DSC132:
* Standard deviation for 1km double run leveling: 1mm
* Image: Erect
* Magnification: 32X
* Objective aperture: 36mm
* Field of view: 1° 20'
* Minimum focus: 0.3m
* Multiplication constant: 100
* Additive constant: 0
* Sensitivity of bubble: 8' /2mm
* Horizontal Circle-reading: 1degree Or 1 gon
* Compensator range: +/- 15'
* Compensator setting accuracy: +/- 0.5' '
* Instrument net weight: 1.30kg
* Instrument gross weight: 1.85kg
* Tripod Joint: M16 or 5/8' '
Package information of Profession and Accurate Automatic Level DSC132:
* ABS carrying case
* 4 pcs per carton
* Dimensions of carton: 570mm * 410mm * 220mm
* Gross weight of carton: 10kg
* Net weight of carton: 8kg
| MODEL | DSC132 | DSC332 & DSC324 | DSC532 |
| Standard deviation for 1km double run leveling | 1mm | 1mm | 1mm |
| Image | Erect | Erect | Erect |
| Magnification | 32X | 32X & 24X | 32X |
| Objective aperture | 36mm | 38mm | 38mm |
| Field of view | 1° 20' | 1° 20' | 1° 20' |
| Minimum focus | 0.3m | 0.3m | 0.3m |
| Multiplication constant | 100 | 100 | 100 |
| Additive constant | 0 | 0 | 0 |
| Sensitivity of bubble | 8' /2mm | 8' /2mm | 8' /2mm |
| Horiz. circle-reading | 1° or 1gon | 1° or 1gon | 1° or 1gon |
| Compensator range | ± 15' | ± 15' | ± 15' |
| Compensator setting accuracy | ± 0.5' ' | ± 0.5' ' | ± 0.5' ' |
| Net weight | 1.30kg | 1.50kg | 1.70kg |
| Tripod Joint | M16 or 5/8' ' | M16 or 5/8' ' | M16 or 5/8' ' |
