• Model NO.：HF12E
• Application：Heavy Industrial
• Accuracy Class：III Class (Eqv. to OIML R76)
• Internal Resolution：1 000 000 Counts
• Overloading Range：100%F.S.+9e
• Tare Range：100%F.S.
• Loadcell Excitation Voltage：3.00±2% Vdc (typ.)
• AC Power Supply：94 ~ 121 , 187 ~ 242 Vac 50 ~ 60Hz
• Operating Temperature：-10 ~ +40 degC(+14 ~ +104 degF)
• Operating Humidity at 20 Degc：0 ~ 90 % (Rel.)
• Indicator Net Weight：1.55 kg (3.40 lb)
• Transport Package：12PCS,CTN
• Specification：245*178mm
• Trademark：Heavye
• Origin：China
• HS Code：8423900010

Basic Info.

Model NO. HF12E Application Heavy Industrial Accuracy Class III Class (Eqv. to OIML R76) Internal Resolution 1 000 000 Counts Overloading Range 100%F.S.+9e Tare Range 100%F.S. Loadcell Excitation Voltage 3.00±2% Vdc (typ.) AC Power Supply 94 ~ 121 / 187 ~ 242 Vac 50 ~ 60Hz Operating Temperature -10 ~ +40 degC(+14 ~ +104 degF) Operating Humidity at 20 Degc 0 ~ 90 % (Rel.) Indicator Net Weight 1.55 kg (3.40 lb) Transport Package 12PCS/CTN Specification 245*178mm Trademark Heavye Origin China HS Code 8423900010

Product Description

Description

Enhanced ABS plastic enclosure
Stainless steel bracket
large 6-digit display
6-button keypad

Features

6-digit 1.2inch super luminant LED display
6-digit 40mm LCD display with LED backlight
6-key flat tact switch
One configurable user-defined function key
One configurable software set-point
Supports 4- and 6-wire loadcell connections
Drives up to 4X350ohm or 8X700ohm loadcells
Built-in 6V/4.0Ah rechargeable battery

Specifications


Auto-Zero range: ±20%F.S.
Manual-Zero range: ±4%F.S.
Center of Zero: ±0.25e
Return-to-Zero Range: 5.0e
Zero-tracking: 0.5e/s
Full Scale Input Signal: -19.5 ~ +19.5 mV (-3.9 ~ +3.9 mV/V)
Differential Input Current: +/-2 nA (typ.)
Measurement Rate: 10 measurements/s
System Linearity: +/-6 ppm (typ.)
System Offset Error: +/-3 ppm of F.S. (typ.)
System Offset Drift: +/-10 nV/degC (typ.)
System Gain Error: +/-0.8 %F.S. (typ.)
System Gain Drift: +/-4 ppm/degC (typ.)
Fusing: 1.1A PPTC resettable fuse
Low Battery Caution: 5.80 Vdc (typ.)
Low Battery Auto Power-Off: 5.60 Vdc (typ.)

Options

Measurement unit switch function
Preset tare function
Calibration switch with seal protection
One full duplex RS-232 serial port
One RS-485 serial port
One RS-232 extended printer port
Full time and date stamping clock
