Granite Inspection Plate and Plate Stand
Qingdao Tide Machine Tool Supply Co., Ltd.- Type：Inspection Surface Plate
- Material：Granite
- Measurement Object：Flatness
- Range：All Size
- Resolution：0.001mm
- Precision：0.001mm
Base Info
- Model NO.：641-
- Measure Method：Manual
- Accuracy：A
- Precision Measuring Device：Precision Measuring Device
- Certification：JIS, DIN, GB, CE, RoHS, ISO
- Customized：Customized
- Transport Package：Wooden Cases
- Specification：150mm-2000mm
- Origin：China
- Production Capacity：1000PCS,Month
Description
Basic Info.
Model NO. 641- Measure Method Manual Accuracy A Precision Measuring Device Precision Measuring Device Certification JIS, DIN, GB, CE, RoHS, ISO Customized Customized Transport Package Wooden Cases Specification 150mm-2000mm Origin China Production Capacity 1000PCS/MonthProduct Description
Granite Inspection Plate and Plate Stand1.We can supply all kinds of Granite Inspection Plates and Plate Stands to satisfy clients' needs.
2.We are able to manufacture Granite Inspection Plates and Plate Stands according to clients' drawings.
3.Our Granite Inspection Plates and Plate Stands are acknowledged and very popular in the international market.
4.We are willing to provide clients with our samples of Granite Inspection Plates and Plate Stands if being requested.
5.Welcome to send detailed enquiries with our model number and your quantity of Granite Inspection Plates and Plate Stands to us to begin our business.
| Overall | 0-Ledge | 2-Ledge | ||
| Size | Thickness | Accuracy | Model No. | Model No. |
| 9x12" | 3" | 0.000050' ' | 640-0400 | 640-0402 |
| 12x12" | 3" | 0.000050' ' | 640-0410 | 640-0412 |
| 12x18" | 3" | 0.000050' ' | 640-0420 | 640-0422 |
| 18x18" | 3" | 0.000050' ' | 640-0430 | 640-0432 |
| 18x24" | 3" | 0.000075' ' | 640-0440 | 640-0442 |
| 24x24" | 3" | 0.000075' ' | 640-0450 | 640-0452 |
| 24x36" | 4" | 0.0001' ' | 640-0470 | 640-0472 |
| 36x48" | 4" | 0.0002' ' | 640-0473 | 640-0482 |
| 36x48" | 6" | 0.0002' ' | 640-0480 | 640-0483 |
| 36x60" | 6" | 0.00025' ' | 640-0490 | 640-0492 |
| Overall | 0-Ledge | 2-Ledge | ||
| Size | Thickness | Accuracy | Model No. | Model No. |
| 9x12" | 3" | 0.000025' ' | 640-0600 | 640-0602 |
| 12x18" | 3" | 0.000025' ' | 640-0620 | 640-0622 |
| 18x24" | 4" | 0.000037' ' | 640-0640 | 640-0642 |
| 24x36" | 6" | 0.000050' ' | 640-0660 | 640-0662 |
| 36x48" | 6" | 0.0001' ' | 640-0680 | 640-0682 |
| Overall | 0-Ledge | 2-Ledge | ||
| Size | Thickness | Accuracy | Model No. | Model No. |
| 5x6" | 2" | 0.0001" | 640-0070 | 640-0177 |
| 6x8" | 2" | 0.0001" | 640-0080 | 640-0188 |
| 8x12" | 2" | 0.0001" | 640-0090 | 640-0199 |
| 9x12" | 2" | 0.0001" | 640-0101 | 640-0103 |
| 9x12" | 3" | 0.0001" | 640-0100 | 640-0102 |
| 12x12" | 3" | 0.0001" | 640-0110 | 640-0112 |
| 12x18" | 3" | 0.0001" | 640-0120 | 640-0122 |
| 12x18" | 4" | 0.0001" | 640-0125 | 640-0126 |
| 18x18" | 3" | 0.0001" | 640-0130 | 640-0132 |
| 18x24" | 3" | 0.0001" | 640-0140 | 640-0142 |
| 18x24" | 4" | 0.00015" | 640-0145 | 640-0146 |
| 24x24" | 3" | 0.00015" | 640-0150 | 640-0152 |
| 24x36" | 4" | 0.0002" | 640-0160 | 640-0162 |
| 24x48" | 4" | 0.0003" | 640-0170 | 640-0172 |
| 36x48" | 4" | 0.0004" | 640-0180 | 640-0182 |
| 36x48" | 6" | 0.0004" | 640-0184 | 640-0186 |
| 36x60" | 6" | 0.0005" | 640-0190 | 640-0192 |
| 36x72" | 6" | 0.0006" | 640-0200 | 640-0202 |
| 48x60" | 6" | 0.0005" | 640-0210 | 640-0212 |
| 48x72" | 6" | 0.0007" | 640-0220 | 640-0222 |
| 48x84" | 8" | 0.0007" | 640-0230 | 640-0233 |
| 48x96" | 12" | 0.0008" | 640-0240 | 640-0241 |
| Grade 0 | Grade 00 | |
| Size | Model No. | Model No. |
| 300x200x50mm | 641-0001 | 641-0070 |
| 300x300x50mm | 641-0005 | 641-0075 |
| 400x250x50mm | 641-0010 | 641-0080 |
| 400x400x100mm | 641-0015 | 641-0085 |
| 500x315x70mm | 641-0016 | 641-0086 |
| 630x400x80mm | 641-0018 | 641-0088 |
| 630x400x100mm | 641-0020 | 641-0090 |
| 630x630x100mm | 641-0022 | 641-0092 |
| 630x630x130mm | 641-0025 | 641-0095 |
| 800x500x100mm | 641-0028 | 641-0098 |
| 800x500x130mm | 641-0030 | 641-0100 |
| 1000x630x100mm | 641-0034 | 641-0104 |
| 1000x630x150mm | 641-0035 | 641-0105 |
| 1000x750x150mm | 641-0040 | 641-0110 |
| 1000x1000x150mm | 641-0045 | 641-0115 |
| 1200x800x150mm | 641-0047 | 641-0117 |
| 1200x800x160mm | 641-0048 | 641-0118 |
| 1600x1000x180mm | 641-0049 | 641-0119 |
| 1600x1000x200mm | 641-0050 | 641-0120 |
| 1500x1000x200mm | 641-0051 | 641-0121 |
| 2000x1000x250mm | 641-0055 | 641-0125 |
| 2000x1600x300mm | 641-0060 | 641-0130 |
| 2500x1600x300mm | 641-0065 | 641-0135 |
| 3000x1000x400mm | 641-0066 | 641-0136 |
| 3000x2000x400mm | 641-0067 | 641-0137 |
| Size | Model No. | Size | Model No. |
| 400x250mm | 641-3005 | 800x800mm | 641-3050 |
| 400x400mm | 641-3010 | 1000x630mm | 641-3055 |
| 500x400mm | 641-3015 | 1000x750mm | 641-3060 |
| 500x500mm | 641-3020 | 1000x800mm | 641-3065 |
| 600x500mm | 641-3025 | 1000x1000mm | 641-3070 |
| 600x600mm | 641-3030 | 1200x800mm | 641-3075 |
| 630x400mm | 641-3035 | 1500x1000mm | 641-3080 |
| 630x600mm | 641-3036 | 1600x1000mm | 641-3085 |
| 630x630mm | 641-3040 | 2000x1600mm | 641-3090 |
| 800x500mm | 641-3045 | 2500x1600mm | 641-3095 |
