RV Weighing Axle Wheel Scale
Ningbo Jiangbei Shiquan Gifts Co., Ltd.- Structure：Mechanical and Electrical Scale
- Sensor：Analogue Scale
- Installation：Weighbridge
- Automation：Automation
- The Weighing Method：Static Truck Scale
- Scale Structure：Channel-Section Steel
Base Info
- Model NO.：AS002-3040
- Operating Environment：Explosion-proof Loadometer
- Signal Output Mode：Wireless and Wired Options
- Material：Aluminum-Alloy
- Service：OEM&ODM
- Power Supply：110V , 220V or According to Customer
- Production Time：25~45 Days
- Weighing Capacity：1,2,3,5,6t,Weigh Pad
- Defend Grade：IP66
- Net Weight：12kg
- Transport Package：Carton, Wooden Box, Tool Box
- Trademark：SAINTBOND truck axle scale
- Origin：Zhejiang, China
- Production Capacity：8500 Sets Per Month
Description
ModelSize(A×B×C) Capacity (mm) (Each Weighing Pad) AS002 300×400×56mm 500~5000Kg
| Rated load:1/2/3/5/6t/weigh pad | Compensated temp.range: -10~+50ºC |
| Dynamic error : 3 (5~10km/h)%F.S | Static error:0.1~0.3%F.S |
| Static comprehensive error: 0.1~0.5%F.S | Insulation resistance: ≥5000MΩ(100VDC) |
| Rated output:1.0±0.1mV/V | Use temp.range: -30~+80ºC |
| Non-linearity: 0.2%F.S | Temp.effect on zero: 0.03F.S/10ºC |
| Error on corners: 0.2%F.S | Temp.effect on span: 0.05F.S/10ºC |
| Repeatariy: 0.05%F.S | Safe overload: 120% |
| Zero balance: ±1%F.S | Ultimate overload: 150% |
| Excitation voltage: 9~15VDC | Net weight: 12kg |
| Recommended voltage: 10V | Defend grade: IP66 |
