Anpt (L1) Thread Plug Cauge
Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.- Type：Thread Plug Cauge
- Measurement Object：Inside Diameter
- Test Methods：Indicator Method
- Material：Steel
- Precision Gauge：Precision Gauge
- Certification：Mil-P-7105b
Base Info
- Model NO.：ANPT
- Usage：For Working
- Shape：Hexagon
- Customized：Non-Customized
- Transport Package：Carton or Wooden Case
- Specification：1,8-27ANPT
- Trademark：TR Solids Control
- Origin：Xi′an, China
- HS Code：9017300000
- Production Capacity：10000PCS,Month
Description
Basic Info.
Model NO. ANPT Usage For Working Shape Hexagon Customized Non-Customized Transport Package Carton or Wooden Case Specification 1/8-27ANPT Trademark TR Solids Control Origin Xi′an, China HS Code 9017300000 Production Capacity 10000PCS/MonthProduct Description
ANPT(L1)Thread Plug Cauge
Features
The standard conforms to America Aeronautical National Form MIL-P-7105B
Specifications
Unit:mm
| Thread Size | T.P.I | L1 | L2 | D |
| 1/8-27ANPT | 27 | 4.102 | 6.702 | 10.123 |
| 1/4-18ANPT | 18 | 5.786 | 10.205 | 13.461 |
| 3/8-18ANPT | 18 | 6.096 | 10.358 | 16.900 |
| 1/2-14ANPT | 14 | 8.128 | 13.556 | 21.060 |
| 3/4-14ANPT | 14 | 8.611 | 13.861 | 26.405 |
| 1-11 1/2ANPT | 11 1/2 | 10.160 | 17.343 | 33.051 |
| 1 1/4-11 1/2ANPT | 11 1/2 | 10.668 | 17.952 | 41.808 |
| 1 1/2-11 1/2ANPT | 11 1/2 | 10.668 | 18.376 | 47.878 |
| 2-11 1/2ANPT | 11 1/2 | 11.074 | 19.216 | 59.916 |
